DiskStation DS124
Smooth data management in a mini form factor

Synology Products
Synology DiskStation
Synology DiskStation DS124 1 Bay SAN/NAS Storage System
#DS124
Our Price: Request a Quote

Want to build a custom bundle? Contact us!

Click here to jump to more pricing!

Please Note: All Prices are Inclusive of GST

Overview:

Mini Data Management Hub

Bring scattered data under control with the DS124, a super compact data hub that empowers effortless data centralization, organization, and sharing


Take command of your most important data

cloud icon

Secure private cloud

Anywhere, anytime secure access to all your data.

dat sharing icon

Data sharing made easy

Streamline teamwork and access to shared files.

back up icon

Hassle-free backups

Effortlessly protect files using intuitive tools.


Productivity in the private cloud

DS124 is designed for professionals to share, sync, and work together more efficiently.


Anytime, anywhere access

Access, manage, and share your files and media from anywhere with Synology Drive. Available on PC, Mac, Linux, Chromebook, Android, iOS, or any device equipped with a browser.

anywhere access image

on demand image

Intelligent backup and syncing

Safeguard against ransomware attacks or accidental deletion with real-time or scheduled folder backups. Reduce local storage use with on-demand sync, only downloading files as needed.


Seamless cloud syncing

Synchronize files between your DS124 and public cloud services using Synology Cloud Sync. Retain local backup copies of data stored on Google Drive, Dropbox, Microsoft OneDrive, and more, and ensure data ownership.

sync image

across image

Sync up with teams, even at the edge

Use your DS124 to manage all your documents, photos, and other files, or protect your physical assets with professional video surveillance.

Features:

Store, share, and protect

Manage all your documents, photos, and other files, back up applications and devices, or protect your assets with professional video surveillance.


Photo management

Organize your photos and videos with smart and intuitive features. Browse automatically generated albums using facial recognition, geolocation, tags, and more.
Securely share media with others while leveraging enhanced privacy features for greater peace of mind. Create a Shared Space to work together with invitees using a folder-based media library.

Video surveillance

Choose from over 8,300 IP cameras or ONVIF devices compatible with Synology Surveillance Station to keep your premises secure.
Watch live camera streams through web browsers, desktop clients, or mobile apps. Get notified of events and take immediate action.

Add an extra layer of protection

Back up your entire Synology device, including system settings and applications, or select specific folders. Transfer all backup data to multiple destinations using Hyper Backup.
Take your data protection to the next level by creating automatic point-in-time snapshots of shared folders that can be copied off-site and rapidly restored using Snapshot Replication.

Specifications:

DS220+ Hardware Specs

CPU

CPU Model Realtek RTD1619B
CPU Core 4
CPU Architecture 64-bit
CPU Frequency 1.7 GHz
Hardware Encryption Engine

Memory

System Memory 1 GB DDR4 non-ECC
Notes Synology reserves the right to replace memory modules with the same or higher frequency based on supplier's product life cycle status. Rest assured that the compatibility and stability have been strictly verified with the same benchmark to ensure identical performance.

Storage

Drive Bays 1
Compatible Drive Type* (See all supported drives)
  • 3.5" SATA HDD
  • 2.5" SATA HDD
  • M.2 2280 NVMe SSD
Hot Swappable Drive -

External Ports

RJ-45 1GbE LAN Port 1
USB 3.2 Gen 1 Port 2
Notes This device's 1GbE LAN ports have a maximum transmission unit (MTU) size of 1,500 bytes.

Appearance

Size (Height x Width x Depth) 166 mm x 71 mm x 224 mm
Weight 0.7 kg

Others

System Fan 60 mm x 60 mm x 1 pcs
Fan Speed Mode
  • Full-Speed Mode
  • Cool Mode
  • Quiet Mode
Brightness Adjustable Front LED Indicators
Power Recovery
Noise Level* 19.0 dB(A)
Scheduled Power On / Off
Wake on LAN / WAN
Power Supply Unit / Adapter 36 watts
AC Input Power Voltage 100 V to 240 V AC
Power Frequency 50/60 Hz, Single Phase
Power Consumption* 10.69 watts (Access)
3.44 watts (HDD Hibernation)
British Thermal Unit 36.50 BTU/hr (Access)
11.75 BTU/hr (HDD Hibernation)
Notes
  • For more information on how power consumption is measured, refer to this article.
  • Noise testing was conducted with the Synology system fully installed with Synology SATA HDDs and in an idle state. Two GRAS 40AE microphones are placed at a 1 m distance from the front and rear of the device. Background noise: 16.49-17.51 dB(A); Temperature: 24.25-25.75˚C; Humidity: 58.2-61.8%

Temperature

Operating Temperature 0°C to 40°C (32°F to 104°F)
Storage Temperature -20°C to 60°C (-5°F to 140°F)
Operating humidity 8% to 80% RH
Relative Humidity 5% to 95% RH

Certification

  • UKCA
  • BIS
  • EAC
  • VCCI
  • CCC
  • RCM
  • KC
  • FCC
  • CE
  • BSMI

Warranty

2-year hardware warranty, extendable to 4 years with Extended Warranty Plus
Notes
  • The warranty period starts from the purchase date as stated on your purchase receipt.
  • Extended Warranty Plus is only available in Europe and North America. Refer to the Extended Warranty Plus website for details on supported countries/regions

Environment

RoHS Compliant

Packaging Content

  • Main Unit X 1
  • Accessory Pack X 1
  • AC Power Adapter X 1
  • AC Power Cord X 1
  • RJ-45 LAN Cable X 2

Optional Accessories

  • Plus Series 3.5" SATA HDD: HAT3300 Series

Documentation:

Download the Synology DiskStation DS124 Datasheet  (PDF).

It appears you don't have a PDF plugin for this browser. No biggie... you can click here to download the PDF file.
